AR Coating Material

Nonmetal Coating materials

AR Coating Material

일반 진공 증착용 코팅 재료
SiO2, ZrO2, I.T.O, TiO2, Al2O3 등을 직접 생산, 판매

특수 진공 증착용 코팅 재료
SV-5(OH-5), SV-20(OS-50), SV-7(고굴절용),
SV-8(중굴절용) SV-21(Ti+Al), SV-55(SiO2+Al2O3), SV-71(OA-600)등

접착력 향상을 위한 보조 코팅 재료
SV-10, SiO, Cr

3) Nonmetal Coating meterials


Cat.
No.
MaterialsFormulaOrder
Information
Refractive
Index/Wavelength
Transmission
Range
Evaporation
Temperature
Notes
7610AluminiumAIF3Granules

about 1-3mm
1.35 at 500 nm200 – 8000 nm800–1000 nmUV - Coatings
8012Aluminium 0XideAi2O3Granules

about 1-2.5mm
1.63 at 550 nm200 – 5000 nm2000-2200 ℃Multilayers

Protective Films
8013Granules

about 1-2mm
8014Tablets about 1g

Ø10.5mmX3.5mm
8015Granules

about 1-3.5mm
8016Granules

about 1-4mm
8017Granules

about 3-5mm
8018Granules

about 4-6mm
8019Granules

about 1-3mm
80143Granules

about 1-3mm
1710Barium FluorideBaF2Granules

about 1-4mm
1.48 at 500 nm250 – 15000 nm1300-1500 ℃IR – transparent

Layers
2711Calcium FluorideCaF
2
Granules

about 1-4mm
1.48 at 550 nm150 – 12000 nm1400-1450 ℃
2263Cerium(Ⅲ) FluorideCeF3Granules

Less than 1mm
1.63 at 500 nm300 – 5000 nm1400-1600 ℃Multilayers

Antireflection

Coatings
2260Granules

Less than 1-3mm
2261Granules

Less than 1-4mm
2262Granules

Less than 2-4mm
2264Tablets

about Ø7mmX5.3mm
6023Cerium (Ⅳ) OxideCeO2Granules

about 1-3mm
2.0 at 500 nm
1.63 at 550 nm
400 – 16000 nmAbout 2000 ℃Multilayers

Antireflection

Coatings
6022Tablets

Ø20mm X 15mm
2410Chromium (Ⅲ)OxidePowder less than

0.3 mm
2.4 at 1800 nm1200 – 10000 nm1900 – 2000 ℃Absorbing Layers for

Optical Lenses
1610Dysprosium FluorideDyf2Granules

about 1-4mm
1.56 at 500 nm220 – 12000 nm1200 – 1300 ℃IR – Coatings
1501Hafnium(Ⅳ) Oxide UVHfO2Tablets about 2g

Ø9mm X 4.2mm
1.9 at 500 n230 – 7000 nm2300 – 2500 ℃Multilayers esp. for

UV spectral region
1502Granules

about 1-4mm
1503Tablets

Ø 14mm X 5mm
3110Iron(Ⅲ) OxideFe2O3Granules

about 1-4mm
3.0 at 550 nm
1129Lanthanum(Ⅲ) FluorideLaF3Granules

about 1-3mm
1.60 at 500 nm220 – 14000 nm1200 – 1600 ℃Multilayers
1911Lanthanum OxideLaF3Granules

about 1-4mm
2.0 at 500 nm
8221Magnesium OxideMgOGranules

about 1-3mm
1.70 at 550 nm200 – 8000 nm1700℃
8021Magnesium FluorideMgF2Granules

about 1-2.5mm
1.38 at 550 nm200 – 7000 nm1300 – 1600 ℃Antireflection

Coatings

Protective Films

Multilayers on Glass,

Plastics and Jewelry
8022Granules

about 2-4mm
8023Granules

about 1-3mm
8024Granules

about 1-1.5mm
8025Magnesium FluorideMgF2Granules

about 4-6mm
1.38 at 550 nm200– 7000 nm1300 - 1600℃Antireflection

Coatings

Protecive Films

Multilayers on Glass,

Plastics and Jewelry
8026Granules

about 0.7-1.2mm
8027Granules

about 1-2mm
8028Granules

about 3-4mm
6410CryoliteNa3 AIF6Granules

about 1-4mm
1.33 at 500 nm250 – 14000 nm800 -1200℃Multilayers
2210ChiolitheNa5Al3F14Granules

about 1-4mm
1.33 at 500 nm250 – 14000 nm800 - 1000℃Multilayers

Antireflection

Coatings
2211Tablets about 0.5g

Ø11mm X 3.6mm
6710Neodymium(Ⅲ) FluorideNdF3Granules

about 1-4mm
1.60 at 500 nm170 – 14000 nm1200 - 1600℃Multilayers
9311Neodymium(Ⅴ) OxideNd2 O3Granules
about 1-3mm
2.1 at 550 nm1800 - 1860℃
3070Niobium OxideNb2O5Granules

about 1-3mm
2.3 at 550 nm350 – 1000 nm1800 - 1900℃
3071Granules

about 1-4mm
7310Lead(Ⅱ) FluoridePbF
2
Granules

about 1-4mm
1.75 at 500 nm250 – 17000 nm700 - 1000℃Multilayers
8067Silicon MonoxideSiOGranules

about 1.5-3mm
1.8 at 1000 nm800 - 8000 nm1200 - 1600℃Multilayers

Barrier Layers

Antireflection Coatings

Protective Films

Jewelry
8068Granules

about 2-3mm
8069Granules

about 2-4mm
8070Granules

about 1-3mm
8071Silicon MonoxideSiOGranules

about 5-8mm
1.8 at 1000 nm800 – 8000 nm1200 - 1600℃Multilayers

Barrier Layers

Antireflection Coatings

Protective Films

Jewelry
8072Granules

about 1-2mm
8073Granules

about 1-4mm
8074Granules

about 3-5mm
8075Granules

about 6-12mm
8076Granules

about 6-10mm
8077Granules

about 13-16mm
8078Granules

about  #50 mesh
8079Granules

about  #100 mesh
8080Granules

about 4-6mm
8061Silicon DioxideSiOGranules

about 0.5-7mm
1.46 at 500 nm200 – 2000 nm1800 - 2200 ℃Multilayers


Hard Coatings of low

Refractive Index


Dielectric Coatings
8062Granules

about 1-3mm
8063Granules

about 2-4mm
8064Granules

about 1-2.5mm
8065Granules

about 1-2mm
8066Granules

about 3-5mm
80622Granules

about 1.5-3mm
80623Granules

about 0.8-1.8mm
80661Granules

about 5-10mm
8561Disc

Ø22mm X 10mm
8562Disc

Ø25mm X 10mm
8563Disc

Ø30mm X 10mm
8564Disc

Ø60mm X 10mm
8565Disc

Ø25mm X 10mm
80624“P”-typeGranules

about 1-3mm
80625“P”-typeGranules

about 0.8-2.5mm
7021Tnatalum(V) OxideTa2 O5Granules

about 1-3mm
2.1 at 500 nm300 – 7000 nm1900- 2200℃Multilayers

Dielectric films for

Thin film capacitors
7022Granules

About 1-5mm
7023Tablets

Ø14mm X 8mm
70211Granules (Black)

about 1-3mm
8172Tablets about 0.5g

Ø7mm X 3mm
8301Titanium(Ⅱ) OxideTiOGranules

about 2-4mm
1700 - 2000℃Antireflection

Coatings

Interference Filters

Protective Films

Beam Splitters

Jewelry
8303Granules

about 0.8-2mm
8304Tablets about 1g

Ø9.4mm X 4.5mm
8281Titanium(Ⅲ) OxideTi2 O3Tablets about 1g

Ø9.2mm X 7.5mm
1800 - 2000℃Antireflection

Coatings

Interference Filters

Protective Films

Beam Splitters

Jewelry
8282Granules

about 1-3mm
8081Titanium(Ⅳ) OxideTiO2Tablets about 1g
Ø8.7mm X 5mm
2.4 at 500 nm4000 – 2000 nm2000- 2200 ℃Highly refractive

Layers

Multilayers
8082Tablets about 2g

Ø13mm X 5.5mm
8083Granules

about 1-2.5mm
8084Granules

about 1-4mm
8085Granules

about 3-5mm
8086Granules

about 2-4mm
8087Granules

about 1-3mm
8091Yttrium OxideY2O3Tablets about 1g
Ø10.7mm X 4.7mm
1.79 at 500 nm250-8000 nm2300- 2500℃Multilayers

Insulating layers
8092Granules

about 1-2.5mm
1810Ytterbium FluorideYbF3Granules
less 1mm
1.52 at 500 nm220– 12000 nm1200- 1300℃I R – Coatings
8710Yttrium FluorideYF3Granules

Less than 1mm
1.3 at 10600 nm200– 14000 nmAbout 1100℃I R – Coatings
3571Zinc OxideZnOGranules

Less than 1-3mm
2.0 at 550 nm400-16000 nm100 - 1210℃
8810Zinc SelenideZnSeGranules

about 1-4mm
2.6 at 630 nm600-15000 nm600- 900℃Multilayers, IR-Filters,

Color Filters
3541Zinc SulfideZnSTablets about 1g

Ø10mm X 6mm
2.4 at 550 nm400-14000 nm1000 - 1100℃Multilayers

Protective Films

Cold Light Mirrors

Beam Splitters
3542Granules

about 1-4mm
3543Poweder

Less than 1mm
